TRIUMPH 2010 STREET TRIPLE 675R – Rick – MOTO 2 REPLICA – FITTING EXAN AND BELLYPAN
Belly won’t fit with new Underslung Mufffler Sellotape on to not mark the Gelcoat then mark out the cut The bellypan cut to shape Bellypan fitted allowing for plenty of space between the muffler exhaust
TRIUMPH 2010 STREET TRIPLE 675R – Rick – MOTO 2 REPLICA – EXAN LOW SLUNG MUFFLER WITH LINK PIPE
I had no option but to find an exhaust with a link pipe to replace the dual yoke system which would not fit on on the Daytona oem sub chassis. This is stainless steel with a carbon tip. I will need to tweak the belly pan slighty. Take the rearsets off and undo the main […]
TEAMCAVE – TRIUMPH 2010 STREET TRIPLE 675R – Rick – MOTO 2 REPLICA – AWAITING PARTS
Some parts still to come in to progress the build of Chitty Chitty Bang Bang
TEAMCAVE – TRIUMPH 2010 STREET TRIPLE 675R – Rick – MOTO 2 REPLICA – SATO REARSETS INSTALL
Rear set bent in towards the trailing arm Foot peg bent – really difficult to do – must have put some real pressures on this. RHS rear brake rear sets on – simple install not many pics OEM LHS gear change rearset Front plate, note the spacer and on what part of the plate it […]
TEAMCAVE – TRIUMPH 2010 STREET TRIPLE 675R – Moto 2 Aero Kit Conversion – Installation Phase 3 – Rear
TEAMCAVE STR675R – MOTO 2 REPLICA – REAR – 01 REAR ASSEMBLY STILL ON TEAMCAVE STR675R – MOTO 2 REPLICA – REAR – 02 2012 DAYTONA SUB CHASSIS TOP VIEW TEAMCAVE STR675R – MOTO 2 REPLICA – REAR – 03 2012 DAYTONA SUB CHASSIS SIDE VIEW TEAMCAVE STR675R – MOTO 2 REPLICA – REAR – […]
TEAMCAVE – TRIUMPH 2010 STREET TRIPLE 675R – Moto 2 Aero Kit Conversion – Installation Phase 2
Here we go again
TEAMCAVE – TRIUMPH 2010 STREET TRIPLE 675R – Moto 2 Aero Kit Conversion – Installation Phase 1
Time to start the fun job of fixing the fairings and other stuff. Leaving the brochure here as used it for the guide and confirmation of locations. Brochure and Instructions There are two ways to remove the oem headstock. First is the quicker way by not removing the tank etc… 2nd is removing the tank, […]
TEAMCAVE – TRIUMPH 2010 STREET TRIPLE 675R – MOTO 2 AERO KIT – REMOVAL
The kit has arrived and managed to grab an hour at the weekend to have a little play with the parts. I could probably work where the brackets for the fairing parts go but why waste time. Found the instructions on the bbt moto site. These are a powerpoint converted to pdf by the looks […]
TEAMCAVE – BBT RACING
Let’s bring the #moto2style to the world and race it within our constantly growing TRIUMPH racing community!Join and race your TRIUMPH with like-minded people!…now it’s your turn! The 𝔹𝔹𝕋.𝕊𝕦𝕡𝕖𝕣𝕥𝕣𝕚𝕡𝕝𝕖𝕤 -series was born in purpose to give lovers of british sports bikes a home for theirs racing ambitions. It is designed from scratch in order to […]
Moto2 Fairings On the way
yeah Track fairings on the way
